CAT6a UTP Flat Patch Cable 32AWG Snagless Molded Boot Copper

NEETUO premium CAT6a UTP Flat Patch Cable is made of 32AWG stranded pure copper conductor with unshielded twisted pair. Each end is molded with RJ45 crystal plug booted. Snagless design protects the locking clips on the RJ45 connectors from being damaged or snapped off during installation. It’s easier to install around furniture and under carpets. Easily and seamlessly make the cable run along walls, following edges and corners, making them completely invisible.

Overview

NEETUO premium CAT6a UTP Flat Patch Cable is made of 32AWG stranded pure copper conductor with unshielded twisted pair. Each end is molded with RJ45 crystal plug booted. Snagless design protects the locking clips on the RJ45 connectors from being damaged or snapped off during installation.

It’s easier to install around furniture and under carpets. Easily and seamlessly make the cable run along walls, following edges and corners, making them completely invisible.

 Features:

●Suitable for high-density environment

●The unique flat shape makes the installation and wiring more flexible and secure

●Exceed ANSI/TIA-568-D.2 Category 6a and ISO 11801 Class Ea Standards

●Up to 550MHz with 10G Speed, Support PoE/PoE+/PoE++ (IEEE 802.3af/at/bt)

●Performance Tested with Fluke and Wired T568B

●Strain Relief and a Flexible Boot Simplify Moves, Additions and Changes

●Flexible Stranded Cable and RJ45 Modular Plugs with 50μ'' Gold-plated Contacts

●Use in Voice/Video/VoIP Systems in Local Area Network

●Support Current and Future Category 6a/6/5e/5 Applications

 Specification:


印字Printing   Mark

NEETUO LAN CABLE CAT6a UTP FLAT   Stranded COPPER TIA/EIA568.B  xx/xx/xxxx    xxxxm

规格Category

CAT6a

屏蔽类型Shielding

非屏蔽Unshielded

导体Conductor

32AWG多股 纯铜 32AWG Stranded  Copper Wire

绝缘Insulation

HDPE

地线Grouding   Wire

/

撕裂线Rip   Cord

/

护套Jacket

PVC CM(扁平Flat

外径OD

5.8x1.6mm ±0.3

接头Connector

RJ45水晶头注塑RJ45 Crystal Molded Boot 50μ''

线序Wire   Scheme

T568B, Straight

Operation Temperature

-20 to +75°C

Installation Temperature

-10 to +50°C

 Standards:

ANSI/TIA-568-D.2

ISO/IEC 11801

ANSI/TIA-1096-A (FCC Part 68)

EN50173-1:2011

UL1863

EU Directive 2011/65/EU (RoHS-2)

 Compliant Network Standards:

10BASE-T                 100BASE-TX    100BASE-T4

1000BASE-T             5GBASE-T        10GBASE-T

ATM-25                     ATM-51           ATM-155

100VG-AnyLan         TR-4                 TR-16 Active

TR-16 Passive

 Packing demo:



Network Patch Cord samples photos:


Sample photos 小 JPEG.jpg
