Fiber Count

12

24

48

72

96

Loose   tube

Counts

2

4

4

6

8

Diameter(mm)

1.8

1.8

2.1

2.1

2.1

Thickness(mm)

0.3

0.3

0.3

0.3

0.3

Material

PBT

Water   Blocking

Tube filling compound

Filler

Counts

3

1

1

0

0

Material

PE

Fiber   Counts per tube

6

6

12

12

12

Central   strength member

Material

FRP rod(Coated with PE if needed)

Size/mm

1.4

1.4

1.5

2.2

2.2

Armoring

Matertial

Currugated steel tape

Thickness

Min 0.15mm with coating

Ripcord   Quantity

1

1

1

1

1

Outer   Sheath

Material

HDPE,black

NomThickness(mm)

1.6

1.6

1.6

1.6

1.6

Overal   diameter(nom.)(mm)(±0.2)

9.2*15.7

9.2*15.7

10*16.5

10.7*17.2

12.1*18.6

Cable   Weight/kg

155

153

168

184

215

Tension   Strength

IEC60794-1-2-E1

Short   Term(N)

4000

4000

4000

4400

4400

Long   Term(N)

2000

2000

2000

2200

2200

Crush   Resistance(N/100mm)

IEC60794-1-2-E3

Short   Term

3000

3000

3000

3000

3000

Long   Term

1000

1000

1000

1000

1000

Min.Bending   Radius(mm)

Static

10D( D is the cable diameter)

Dynamic

20D

Temperature

Range (℃)

Storage

-30~+60

Installation

-10~+60

Operation

-30~+70
